e4Q
SK-100140 Discontinued
Quattro is Efficiency and Economical
Having to recharge your LiPo batteries individually in order to power your drone can be such a tedious approach because you might have to wait for many hours before they are all full.
With E4Q, 4 different cells(2-4) batteries at the same time by the four independent ports.
Click
Adjustable charging current
A
2
3
5
short circuit
protection
protection
over current
protection
protection
reverse polarity
protection
protection
DC input
voltage
protection
protection
LED and audible sound
indicate various charging status
indicate various charging status
Specifications
e4Q
This product is a special LiPo battery balance plug charger, which can charge 2S/3S/4S LiPo battery in 4 channals simultaneously. The main power supply is DC input, the port adopts XT60 type, the output port adopts special design interface, and the three kinds of batteries do not need Transfer board. Can be plugged in directly.
Size and Weight
Dimension：128x128x50.5mm
Net Weight：280g
Net Weight：280g
Buttons And Port
The e4Q multi-function charger uses four completely independent but identical circuits with a power output of 50W per power.
It is designed for charging 2-4 LiPo batteries. Insert the battery into the right connector of each port, charge
The appliance will also charge 4 battery times. The charging current can be adjusted by pressing the button 2A / 3A / 5A
The charging capacity can show the charging current in the LED indicator through the color change
Power
DC Input: 11-26.1V
Charge Circuit Power: 4 x 50W ±10%
Charging model: balance charging
Charge Circuit Power: 4 x 50W ±10%
Charging model: balance charging
Charge Current Range: 2A/3A/5A
Charge saturation voltage:4.20V±0.02V/CELL
Balance current :Max 400mA/CELL
Charge saturation voltage:4.20V±0.02V/CELL
Balance current :Max 400mA/CELL
LED light
LED light charging current display
The first three-color LED lights represent Ampere (A)
Green light(Charging current is 2A)
Yellow light(Charging current is 3A)
Red light(Charging current is 5A)
The second tri-color LED light represent capacity (%)
LED light standby status indication:Not bright
LED light standby status indication:Not bright
LED light charging instructions:According to the power, the red light to the green light,And do breathing instructions
LED Light charge finished indication：Accompanied by the sound of the alarm, after 5 flashes,LED glows constant green
Replay
Working and Storage
Working environment
Operating temperature 0℃-40℃
Operating humidity 0%-75%
Operating humidity 0%-75%
Storage environment
storage temperature -10℃-70℃
Storage humidity 0%-75%
Storage humidity 0%-75%
